Rotary Tiller

Hobby Series

Hobby series rotary tillers are built sturdy, for independent use with smaller HP tractors. The optimum size of machine makes it ideal to enter in row plantations along with tractor for having ease of working in intercultural operations and for quality pulverisation of hobby farms.
Hobby series tillers are compatible with small HP tractors up to 40 HP for light application and conditions. It covers more area of tillage with lesser HP resulting in higher productivity. Boron steel blades mulch through thick residue and create the ideal soil texture for planting.

Technical Specification

  Hobby Series
Model WT-X-90 WT-X-105 WT-X-120 WT-X-135 WT-X-150
Size (in feet / m) 905 / 35.6 1055 / 41.5 1205 / 47.4 4.5 / 1.4 5 / 1.5
Working Width
(mm / Inch)
905 / 35.6 1055 / 41.5 1205 / 47.4 1355 / 53.3 1505 / 59.2
Gear Box Single Speed
Side
Transmission
Gear Drive
Types of Blades C – Type
No of Blades 24 30 36 36 42
Gear Box
Overload
Protection
Shear Bolt
Weight (kg / lbs) 154 / 340 169 / 373 181 / 399 193 / 425 204 / 450
Tractor Power
(HP)
15-20 20-30 20-35 25-40 25-40
