Compact Disc Harrow
Worldtrac Compact Disc harrow is designed specifically for stubble cultivation and seedbed preparation. The compact design and aggressive disc angle ensure reliable penetration and excellent mixing in of harvest residues.
Technical Specification
| Compact Disc Harrow | ||||||
| Model | WT-CDH-16 | WT-CDH-18 | WT-CDH-20 | WT-CDH-24 | WT-CDH-28 | WT-CDH-32 |
| No Of Disc | 16 | 18 | 20 | 24 | 28 | 32 |
| Type Of Disc | Front Notched & Rear Plain | |||||
| Disc Diameter (mm / Inch) |
610 / 660 Optional // 24 / 26 Optional | |||||
| Disc Spacing (mm / Inch) | 225 / 8.8 | |||||
| Working Width (mm / Inch) |
1750-1800 / 68.9-70.9 |
2000-2050 / 78.7-80.7 |
2250-2300 / 88.6-90.5 |
2500-2550 / 98.4-100.4 |
2750-2800 / 108.3-110.2 |
3000-3050 / 118.1-120.1 |
| Bearing Hubs | 6 | 8 | 8 | 8 | 8 | 12 |
| Gang Rod (mm / inch) | 32×32 / 1.26×1.26 (Sq. Rod) | |||||
| Mounted | CAT-II | CAT-II/CAT-III | ||||
| Weight (Kg. / lbs Approx.) | 700 / 1543 | 860 / 1896 | 980 / 2160 | 1100 / 2425 | 1250 / 2756 | 1500 / 3307 |
| Tractor Power (HP) |
50-60 | 60-70 | 70-80 | 75-90 | 90-100 | 100-120 |
*Data and specifications are subject to change without any advance notice due to continuous product improvement and development.
